IEC 60335-1 Clause 22.5 Residual Voltage Tester Testing Range 5~150V Test impedance ≥1000 MΩ

Product information:

The Residual Voltage Tester is in accordance with the requirements of IEC 60335-1 Clause 22.5 (GB4706.1 Clause 22.5),IEC 60065 Clause 9.1.6 (GB8898 Clause 9.1.6), IEC 60601-1 (GB9706.1 Clause 15), IEC/EN 60598-1 Clause 8.2.7 (GB7000.1 Clause 8.2.7) and IEC 60950-1 ( GB4943.1 Clause 2.1.1.7).

Features:

1. Power-off test when the power supply voltage of the equipment is at the peak value, ensuring the accuracy and consistency of the test data

2. Test impedance ≥1000 MΩ, meeting the impedance requirements of L-E inter-electrode and accessible capacitor residual voltage and capacity test

3. Multi-form test functions:

A. Residual voltage between each power pin

B. Residual voltage between each power pin and the equipment casing

C. Residual voltage and capacity test of the capacitor accessible outside the equipment

4. Manual/automatic conversion test. That is, you can manually perform phase separation test between poles, test 10 times between each two poles; you can also perform automatic test to complete the test of three-pole combination, and test each combination 10 times.

5. Automatically maintain the maximum test voltage value, and automatically alarm when the test residual voltage exceeds 60/34V.

Technical parameters:

• Output voltage: AC 0~242V;
• Residual voltage testing range: 5~150V;
• Testing time: 1s;
• Testing impedance: 1000 MΩ;
• Testing alarm range: 60/34V;
• Output power: 2000W;
• Testing discrimination: audible and visual alarm, simultaneously cutting off voltage.
