    BS1363-1 Screwless Terminals Thermal Stress Tester For Electrical And Thermal Stresses Test

    Ask Lasest Price
    Brand Name : Sinuo
    Model Number : SN-BS11
    Certification : Calibration Certificate (Cost Additional)
    Price : Negotiable
    Payment Terms : T/T
    Supply Ability : 30 Sets Per Month
    Delivery Time : 30 Days
    • Product Details
    • Company Profile

    BS1363-1 Screwless Terminals Thermal Stress Tester For Electrical And Thermal Stresses Test


    BS1363-1 Screwless Terminals Thermal Stress Test For electrical and thermal stresses Test


    Product Overview:


    The test apparatus conforms to BS1363-1:2016+A1:2018 clause 25.1.1.

    It is used to check whether the screwless terminals can withstand the electrical and thermal stresses occurring in normal use.


    Technical parameters:


    Test StationSingle
    Test Cycles200 cycles, can be preset
    ON/OFF TimeON60min, OFF60min, can be preset
    Test CurrentAC 1~20A±(3%±1A)
    Temperature rise2 channels
    Load0-20A, can be preset, default 14A
