    IEC 60884 Figure 31 Arrangement For Test On Covers Or Cover Plates


    IEC 60884 Figure 31 Arrangement for Test on Covers or Cover-plates

    Product Overview:

    This test apparatus conforms to IEC 60884-1:2013 clause 24.14 figure 31. It is used to verify the required retention and removal force for the cover or cover plate of switch or socket or other parts.

    The cover or cover-plate being fitted on the wall after a sheet of hard material, (1 ± 0,1) mm thick, has been fitted around the supporting frame as shown in figure 31 of IEC 60884-1 : 2013.


    Technical Parameters:

    Test specimenCover or cover plate of switches, sockets
    Test purposeIt is suitable for verifying the required retention and removal force for the cover or cover plate of switch or socket or other parts
    Test principleThe push-pull force meter is used to push or pull the sample with different force values. A 1±0.1mm hard metal gasket should be used to simulate wallpaper around the support frame.
    Equipment structure and characteristicsEquipment dimensions: about: 450×200×200 (mm) W×D×H, equipment weight: 20kg
    Use environment

    Working temperature 0-40℃, humidity 30%-90%;


    Test stationSingle
    Push pull gauge parameters0-200N, division value 0.01N, error <±1%, three units of N/lbf/kgf can be switched
    Test stroke50mm
    Gasket1±0.1mm hard metal
    Operation methodManual
    Accessory86 type concealed box
