    IEC 61032 Figure 12 Test Probe 18 Ф8.6mm Children Finger Probe

    Ask Lasest Price
    Brand Name : Sinuo
    Model Number : SN2210-12
    Certification : Calibration Certificate (Cost Additional)
    Price : Negotiable
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 100 sets per month
    Delivery Time : 3 Days
    • Product Details
    • Company Profile

    IEC 61032 Figure 12 Test Probe 18 Ф8.6mm Children Finger Probe


    IEC 61032 Figure 12 Test Probe 18

    Product Overview:

    This probe conforms to the standard requirements of IEC 61032 figure 12 test probe 18, IEC 60065:2014 clause 9.1.1.3, etc. This probe is intended to simulate access to hazardous parts by children of more than 36 months and less than 14 years.


    Probe Dimension:

    Hemispherical radius (mm)R4.3±0.05
    Finger probe diameter (mm)Ф8.6±0.1
    Finger probe length (mm)57.9±0.15
    Axes of joints distance (mm)19.3
    Collar diameter (mm)Ф38.4±0.3
    Collar length (mm)101.6±0.3
    Extension handle diameter (mm)Ф38.1±0.3
    Extension handle length (mm)451.6±0.8
    Finger probe material (mm)Stainless steel
    Collar and handle material (mm)Nylon
    Operation:

    Please refer to the relevant standards.

    Take IEC 60065:2014 clause 9.1.1.3 as an example:

    The test is repeated using small finger probes according to test probes 18 and 19 of IEC 61032:1997. This does not apply if the intended conditions of use prevent the apparatus from being accessed by children.


    For verifying whether the LIVE PARTS touched, the probe is equipped with amphenol connector, recommended to work with our anti-shock probe experiment device or a 40~50V voltage indicator. Showing as following reference picture:
