    IEC60669 Clause 12.3.12 Figure 10 Voltage Drop Tester For Plugs And Socket


    IEC60669 Clause 12.3.12 and Figure 10 Voltage Drop Tester for Plugs and Socket


    Product Information:

    The Voltage Drop Tester is designed and manufactured according to the standard requirements of IEC60669-1: 2017 clause 12.3.12 and figure 10, IEC60884-1: clause 12.3.12 and figure 12 and etc.

    It is used to check screwless terminals shall be so designed that the connected rigid solid conductor remains clamped, even when it has been deflected during normal installation, for example, during mounting in a box, and the deflecting stress is transferred to the clamping unit.


    Technical Parameters:

    Applied StandardIEC60669-1
    Clause12.3.12 and figure 10
    Test StationSingle
    Deflection Angle0-360°
    Bending DirectionTowards any one of the 30°±3° difference, a total of 12 directions
    Bending Force0.25 N, 0.5 N, 1.0N
    Direction of ApplicationPerpendicular to the direction of the unbending wire
    Operation MethodManual
    Judgement CriterionVoltage-drop not greater than 25 mV or greater than 1 min
